Micro-Computed Tomography (micro-CT) of Book Scorpion Musculature

Application Note for Leica EM CPD300 - Life Science Research

September 01, 2016

Introduction
Species: Book scorpion (Neobisium sp.)
Critical point drying of book scorpion with subsequent X-ray micro-computed tomography (micro-CT) to detect anatomical features with special regard to the musculature.

Procedure
Sample Holder: Sample was transferred to microporous specimen pot and placed into chamber of Filter Discs and Porous Pots holder.


Fixation and Dehydration

Ethanol (70%)overnight
Ethanol series: 80%, 90%, 96%, 100%2x10 min.
Iodine staining (1% iodine solution in 100% ethanol)overnight
Ethanol: 100%2x10 min.

Leica EM CPD300 auto Program:

Fig.1: Volume reconstruction of a book scorpion (outer view and inner view to visualize the musculature).
