Next Generation STELLARIS Confocal Microscope
Next Generation STELLARIS Confocal Platform
STELLARIS is a true confocal point scanning system, including a White Light Laser as excitation light source, an Acousto Optical Beam Splitter (AOBS) and a highly sensitive, prism-based spectral detection design with computer controlled adjustable bandwidth for all fluorescence channels. The extended detection range up to 850 nm plus the excitation range in the visible from 440 nm up to 790 nm (different models available on request) allow the application and separation of an extended range of spectrally overlapping fluorophores.
Including TauSense, a set of tools based on fluorescence lifetime information, it provides an additional contrast, improved image quality and separation of spectrally overlapping fluorophores. LIGHTNING allows for optimal extraction of image details and maximum resolution, thus expanding the imaging portfolio both in the classical range and beyond the diffraction limit.
Components
Next Generation STELLARIS Confocal Microscope includes: |
Quantity |
|
|---|---|---|
 |
Power HyD S SP Core Unit Pos 3158301313 |
1 |
|
SP Light Trap158201310 |
2 |
|
Control panel with LCDs158004752 |
1 |
|
Power HyD S SP pos 2158301312 |
1 |
|
Power HyD S SP pos 4158301314 |
1 |
|
STELLARIS WLL158401100 |
1 |
|
STELLARIS Power cable Zone 2158209011 |
1 |
|
FOV Scanner STELLARIS158301130 |
1 |
|
Fluorifier Disc Basis inkl. Analysator158204510 |
1 |
|
Scan optics HIVISR w.rotation Dmi8/DM8158301120 |
1 |
|
STELLARIS DMi8 adapter158401140 |
1 |
|
Notch filter set VIS base158204511 |
1 |
|
Cable Scanning Stage, 3 m, 90°15500332 |
1 |
|
Obj. HC PL APO 40x/1.30 Oil CS215506428 |
1 |
|
Microscope Objective HC PL APO 20x/0.75 CS215506517 |
1 |
|
Type F Immersion liquid, ISO 803615513859 |
1 |
|
IC Condenser Prism K715521522 |
1 |
|
XY advanced board for scanning stage15525226 |
1 |
|
Smart Move I²C15525232 |
1 |
|
Filter Cube GFP15525314 |
1 |
|
IC Prism C15555009 |
1 |
|
IC Condenser Prism K315555017 |
1 |
|
IC Prism E15555046 |
1 |
|
Aivia Go 1 year27100022 |
1 |
|
Bino Tube155933660 |
1 |
|
Transmission axis155933666 |
1 |
|
DMi8 CS Premium155933668 |
1 |
|
Base Plate DMi8158000640 |
1 |
|
Optical Table 750 x 900 actively damped158002407 |
1 |
|
High Brilliance Monitor158003150 |
1 |
|
Scanning stage inv. universal158004141 |
1 |
|
BF detector for DMI158004201 |
1 |
|
SuperZ Galvo Stage158004421 |
1 |
|
Insert Rotatable Inverse SuperZ158004423 |
1 |
|
pE 300 white MB158200681 |
1 |
|
Laser 405 DMOD158202140 |
1 |
|
Workstation Silver158203114 |
1 |
|
LAS X STELLARIS Control Software158203200 |
1 |
|
DSE powered by Aivia158203220 |
1 |
|
Closed Loop Focus158204201 |
1 |
|
Fluorifier Disc Basis inkl. Analysator158204510 |
1 |
|
Computer table158204709 |
1 |
|
Laser Port 405158301200 |
1 |
|
Service Installation9I_LL_STELLARIS_C |
1 |
|
Confocal Training Class C9T-CLSM-APP_CLASSC |
1 |
|
me Warranty Extension STELLARIS 4059WE_LAS_405 |
1 |
|
Warranty Extension STELLARIS WLL9WE_LAS_WLL |
1 |
|
Warranty Extension9WE_LL_STELLARIS_C |
1 |
STELLARIS can feature a tandem scanning system to provide highest axial resolution with galvanometric scanner, switchable between resonant and non-resonant mode.
STELLARIS can be equipped with Power HyD S detector, new standard for detection. The Power HyD S is an all-round detector with high performance throughout the spectrum and two times increased photon detection efficiency in the blue-green range compared to standard multialkaline photomultiplier. Power Hybrid Detector HyD X and HyD R are specialists for FALCON (FAst Lifetime CONtrast) , FCS and TauSTED Xtend in the visible up to near infrared detection.
Configuration will be tailored to your specific needs – Request a quote
STELLARIS Confocal Microscope Platform
Next generation STELLARIS is a confocal microscope platform designed around your research needs.
STELLARIS confocal microscopes can be combined with all Leica modalities, including FLIM, STED, MP, DLS, and CRS. The next generation STELLARIS confocal platform is your fast track to rewarding research. Power. Potential. Productivity.
