ATTO 520
ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G.
Optical properties
- λ abs = 517 nm
- ε max = 1.1×105 M -1 cm -1
- λ fl = 538 nm
- n fl = 90 %
- τ fl = 3.6 ns
- CF 260 = ε 260 /ε max = 0.16
- CF 280 = ε 280 / ε max = 0.20
ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. Characteristic features of the label are strong absorption, high fluorescence quantum yield, and high thermal and photo-stability. The dye is moderately hydrophilic. Above pH 7.0 the dye exists in an equilibrium with a colorless form (pseudobase). This is a reversible reaction, which does not interfere with the process of coupling to proteins etc. On lowering the pH absorption and fluorescence are restored fully. The fluorescence is excited most efficiently in the range 510 - 535 nm. A suitable source of excitation is an Argon-Ion laser using the 514 nm line.
ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Popular Configurations
Modification |
Unit of measure |
ATTO 520 Amine Fluorescent Label 1 mgProduct No. AD-520-91 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 520 Biotin Fluorescent Label 1 mgProduct No. AD-520-71 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 520 Biotin Fluorescent Label 5 mgProduct No. AD-520-75 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 520 Carboxy Fluorescent Label 1 mgProduct No. AD-520-21 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 520 Carboxy Fluorescent Label 5 mgProduct No. AD-520-25 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 520 Maleimide Fluorescent Label 5 mgProduct No. AD-520-45 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 520 NHS-ester Fluorescent Label 1 mgProduct No. AD-520-31 ATTO 520 is a novel fluorescent label related to the well-known dye Rhodamine 6G. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
