ATTO 633
ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region.
Optical properties
- λ abs = 630 nm
- ε max = 1.3×105 M -1 cm -1
- λ fl = 65 1nm
- n fl = 64 %
- τ fl = 3.3 ns
- CF 260 = ε 260 /ε max = 0.04
- CF 280 = ε 280 / ε max = 0.05
ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. Characteristic features of the label are strong absorption, high fluorescence quantum yield, and high thermal and photo-stability. Thus ATTO 633 is highly suitable for single-molecule detection applications and high-resolution microscopy such as SIM, STED etc. Additionally the dye highly qualifies to be applied in flow cytometry (FACS), fluorescence in-situ hybridization (FISH and many more.
In common with most ATTO-TEC-labels, absorption and fluorescence are independent of pH, at least in the range of pH 2 to 11, used in typical applications. ATTO 633 is a cationic dye. After coupling to a substrate the label carries a net electrical charge of +1.
The label is moderately hydrophilic. Its fluorescence is excited most efficiently in the range 610 - 645 nm. A suitable excitation source for ATTO 633 is the 633 nm line of the He:Ne laser or a diode-laser emitting at 635 nm.
ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Popular Configurations
Modification |
Unit of measure |
ATTO 633 Amine Fluorescent Label 5 mgProduct No. AD-633-95 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 Biotin Fluorescent Label 1 mgProduct No. AD-633-71 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 Biotin Fluorescent Label 5 mgProduct No. AD-633-75 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 Carboxy Fluorescent Label 1 mgProduct No. AD-633-21 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 Carboxy Fluorescent Label 5 mgProduct No. AD-633-25 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 DMPE Labeled Phospholipid 1 mgProduct No. AD-633-191 ATTO-Dye Labeled Phospholipids In recent years the investigation of biological membranes, e.g. intracellular membranes of live cells, plasma membranes etc., has become a major subject of interest. As a result there is a growing demand for fluorescent dye-labeled lipids, in particular glycero-phospholipids, to be incorporated in biological membranes. ATTO offers a variety of glycero-phospholipids, carrying one or two fatty acid chains (lipophilic groups) and a phosphate ester residue (hydrophilic group). ATTO-dye fluorescent phospholipids are labeled at the hydrophilic head group. After incorporation in, e.g., a plasma membrane (phospholipid bilayer) the fluorophore is located at the water/lipid interface of the membrane. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 633 DMPE Labeled Phospholipid 5 mgProduct No. AD-633-195 ATTO-Dye Labeled Phospholipids In recent years the investigation of biological membranes, e.g. intracellular membranes of live cells, plasma membranes etc., has become a major subject of interest. As a result there is a growing demand for fluorescent dye-labeled lipids, in particular glycero-phospholipids, to be incorporated in biological membranes. ATTO offers a variety of glycero-phospholipids, carrying one or two fatty acid chains (lipophilic groups) and a phosphate ester residue (hydrophilic group). ATTO-dye fluorescent phospholipids are labeled at the hydrophilic head group. After incorporation in, e.g., a plasma membrane (phospholipid bilayer) the fluorophore is located at the water/lipid interface of the membrane. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 633 DOPE Labeled Phospholipid 5 mgProduct No. AD-633-165 ATTO-Dye Labeled Phospholipids In recent years the investigation of biological membranes, e.g. intracellular membranes of live cells, plasma membranes etc., has become a major subject of interest. As a result there is a growing demand for fluorescent dye-labeled lipids, in particular glycero-phospholipids, to be incorporated in biological membranes. ATTO offers a variety of glycero-phospholipids, carrying one or two fatty acid chains (lipophilic groups) and a phosphate ester residue (hydrophilic group). ATTO-dye fluorescent phospholipids are labeled at the hydrophilic head group. After incorporation in, e.g., a plasma membrane (phospholipid bilayer) the fluorophore is located at the water/lipid interface of the membrane. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 633 DPPE Labeled Phospholipid 1 mgProduct No. AD-633-151 ATTO-Dye Labeled Phospholipids In recent years the investigation of biological membranes, e.g. intracellular membranes of live cells, plasma membranes etc., has become a major subject of interest. As a result there is a growing demand for fluorescent dye-labeled lipids, in particular glycero-phospholipids, to be incorporated in biological membranes. ATTO offers a variety of glycero-phospholipids, carrying one or two fatty acid chains (lipophilic groups) and a phosphate ester residue (hydrophilic group). ATTO-dye fluorescent phospholipids are labeled at the hydrophilic head group. After incorporation in, e.g., a plasma membrane (phospholipid bilayer) the fluorophore is located at the water/lipid interface of the membrane. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 633 Maleimide Fluorescent Label 5 mgProduct No. AD-633-45 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 NHS-ester Fluorescent Label 1 mgProduct No. AD-633-31 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 Peg(3)-Azide Fluorescent Label 1 mgProduct No. AD-633-101 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 Phalloidin Fluorescent Label 10 nmolProduct No. AD-633-81 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
ATTO 633 PPE Labeled Phospholipid 5 mgProduct No. AD-633-185 ATTO-Dye Labeled Phospholipids In recent years the investigation of biological membranes, e.g. intracellular membranes of live cells, plasma membranes etc., has become a major subject of interest. As a result there is a growing demand for fluorescent dye-labeled lipids, in particular glycero-phospholipids, to be incorporated in biological membranes. ATTO offers a variety of glycero-phospholipids, carrying one or two fatty acid chains (lipophilic groups) and a phosphate ester residue (hydrophilic group). ATTO-dye fluorescent phospholipids are labeled at the hydrophilic head group. After incorporation in, e.g., a plasma membrane (phospholipid bilayer) the fluorophore is located at the water/lipid interface of the membrane. "ATTO-TEC is a wholly owned subsidiary of Leica Microsystems"
Loading...
Loading...
|
ATTO 633 Streptavidin Fluorescent Label 1 mgProduct No. AD-633-61 ATTO 633 belongs to a new generation of fluorescent labels for the red spectral region. ATTO-TEC is a wholly owned subsidiary of Leica Microsystems
Loading...
Loading...
|
