How to Drape an Overhead Surgical Microscope

ARveo 8 & M530 OXH Step-by-step Tutorial

Image source: shutterstock arveo_draping_tutorial.jpg

Microscope draping is critical to maintain a sterile environment and prevent contamination and infections. At Leica, we are committed to supporting you in your surgical practice. In the video below, discover a step-by-step tutorial on how to drape your overhead surgical microscope. The tutorial features the ARveo 8 digital visualization microscope for complex neurosurgery. The procedure also applies to the M530 OHX, OH6, OH5 and OH4.

Key Highlights

Before draping the microscope:

  • Make sure the binocular tubes are configured in the correct position
  • Check that the balancing has been done properly

Microscope draping procedure:

  • Open the drape (to be done by the non-sterile nurse)
  • Unfold the drape
  • Detach the rubber bands
  • Find and lift the lens cover
  • Fasten the lens cover on the microscope
  • Pull the drape over the microscope head and arm
  • Drape the eyepieces
  • Secure with the Velcro straps
  • Put the remaining drape inside the empty space
  • Wrap the bands around the microscope head and arm
  • Use the rubber bands to tighten if necessary

Final steps:

  • Press the SMARS button or the Air Removal button (only available on the ARveo microscope and to be pressed by the circulating nurse)
  • Rotate the microscope to ensure it can be moved easily in all directions

The microscope is now ready to use!
